型号：FMBHJ-6
规格：6000cups/hour
市场价：0.00
优惠价：0.00
This machine is specially designed for liquid and cream products to be filled and sealed, such as yoghurt, ice cream, artificial milk, juice, drink etc. The machine can automatically fill and seal from sending cups, filling, liquid level controlling, putting covers, twice sealing, pushing cups and transporting.
The
machine is a multifunctional high-speed full automatic machine for different
sizes of cups according to clients' requirement. The machine is applied with
world famous electrical and pneumatic components and can be adopted by PLC
system according to clients' requirement. The machine can be equipped with PLC
and touch screen control
Technical parameters:
model
FMBHP-4
production capacity
3000-4000 cups/hour
filling volume
30-300 ml
power
2 KW
Air consumption
0.35m3 /min
power source
220V/ 50Hz
temperature
0-300 ℃
weight
500 kg
dimension range
3150x850x1530 mm
|
model |
FMBHP-6 |
|
production capacity |
5400-6000 cups/hour |
|
filling volume |
30-300 ml |
|
power |
4 KW |
|
Air consumption |
0.65m3 /min |
|
power source |
220V/ 50Hz |
|
temperature |
0-300 ℃ |
|
weight |
800 kg |
|
dimension range |
3150x1000x1530 mm |
model
FMBHP-8
production
capacity
5400-6000 cups/hour
filling volume
30-300 ml
power
6 KW
Air consumption
0.95m3 /min
power source
220V/ 50Hz
temperature
0-300 ℃
weight
1000 kg
dimension range
3350x1500x1530 mm
model
FMBHP-12
production capacity
10000-12000 cups/hour
filling volume
30-300 ml
power
8 KW
Air consumption
1.20m3 /min
power source
220V/ 50Hz
temperature
0-300 ℃
weight
1500 kg
dimension range
3600x1800x1560 mm
