型号：FM-HE-001
规格：1-20Ton/hr
市场价：0.00
优惠价：0.00
1,High heating transferring coefficient
2,high recycle rates
3,high flexibility
4,least idle liquid
5,compact structure
For plates:
*Our production capacity covers more than 300 specification and size plates, the plates function equals to the famous alfa laval, sondex etc brand PHE manufactures,;
*Plate Port diameter 29mm to Port diameter 328mm, plate width from 125mm to 995mm, height from 429mm to 2245mm,thickness from 0.5-1.0mm.
|
Plate material |
Applicable fluids |
|
Stainless steel(SU304.316 ect) |
Clean water, river water, edible oil, mineral oil |
|
Stainless steel & Ti, Ti-Pd |
Sea water, salty water, salt compounds |
|
20Cr, 18Ni,SMO |
Dilute sulfuric acid, water solution of salt matter, Inorganic solution |
|
Nickel |
High temperature and high concentration of caustic soda |
|
Hastelloy |
Concentrated sulfuric acid, Hydrochloric acid, Phosphoric acid |
Gasket
We produce and supply many kinds of gasket for plate heat
exchanger, certified by ISO9001,
|
Rubber Type |
Flu rubber |
EPDM |
NBR |
|
Tensile Strength MPa |
≥13 |
≥16 |
≥17 |
|
Elongation % |
≥120 |
≥170 |
≥200 |
|
Shore A Hardness |
80±5 |
80±5 |
75±3 |
|
Tear Strength KN/M |
≤30 |
≤30 |
≤30 |
|
Compressive Deformation |
24h×23≤2.5 |
24h×23≤5 |
24h×23≤2.5 |
|
|
24h×180≤15 |
24h×150≤15 |
24h×125≤15 |
|
Ozone Resistance |
Excellent |
Excellent |
good |
|
Gasket Material |
Applicable Temperature |
Applicable Fluids |
|
NBR |
-15~+135 |
Water seawater, Mineral oil, Saline |
|
EPDM |
-25~+180 |
Hot water, vapor, acid, alkali |
|
F26 |
-55~+230 |
Acid, alkali, fluids |
|
FTP |
0~+160 |
concentrated acid, alkali, High temperature oil, vapor |
