型号：FMP-UHT-1
规格：1-10Ton/hr
市场价：0.00
优惠价：0.00
| Packaging Detail: | wooden cases |
| Delivery Detail: | 35days |
1 The machien adopts UHT processing metods.
2 strictly sterilize
3 high heat effect
4.lower price and better after sevice
The machine adopts UHT processing method,makes liquid dairy beverage and juice etc strictly sterilized, then into aseptic package, with the sterilization temperature:137degree , warm keeping time:3-5Seconds, or 85-95 degree with in 30 Seconds. or 125 degree with in 15 seconds.
so to keep the original utrition, color and flavour of the beverage and dairy. This machine os of the advantage of high heat recycle, compact and fine structure, and temperature control. Outputting material temperature,and cool packing.
capacity:1-10T/h controling way:semi-autmatic (PLC controlling, touch screen).
| Model | FM-UHT-1 | FM-UHT-2 | FM-UHT-3 | FM-UHT-4 | FM-UHT-5 |
| Production capacity(T/H) | 1 | 2 | 3 | 4 | 5 |
| Heat exchanging Area | 16 | 26 | 36 | 46 | 56 |
| Material inlet temperature | 5 | 5 | 5 | 5 | 5 |
| Material Outlet temperature | 5 | 5 | 5 | 5 | 5 |
| Sterilizing temperature | 137 | 137 | 137 | 137 | 137 |
| Warm keeping times | 4s | 4s | 4s | 4s | 4s |
| Ice water | 1 | 1 | 1 | 1 | 1 |
| Ice water consumption(T/H) | 3 | 4 | 6 | 8 | 12 |
| Joint Size (mm) | 25 | 38 | 38 | 51 | 51 |
| Wight(KG) | 980 | 1080 | 1160 | 1350 | 1650 |
| Size(mm) | 1500*1500*2000 | 1900*1800*2200 | 2100*2200*2500 | 2300*2000*2500 | 2600*2200*2500 |
| Power(KW) | 3 | 4 | 5 | 6 | 7 |
Juice sterilizing machine
Tubular UHT sterilizer
Product introduction: The sterilization process of tubular ultra-high temperature sterilizer not only can be suitable for common products, but also can satisfy special requirements of customers, for example: Long term production of products with granules or medium and high viscosity. Such an cream, pure milk etc. Products(milk, fruit juice and cream )of high viscosity: Products containing fiber and larger pulp granules, products of high acidity and products corrosive to the dead angle. The products can be sterilized at high temperature and ultra-high temperature of 120~140 degree
Main features: Hard to agglomerate, long working time; PLC control with simple and correct operation; Touch screen display, which is direct and full; Self-provided CIPcleaning system, easy cleaning; Reliable materials with high pressure withstanding capacity; Low maintenance cost. It can be customized to satisfy infividualized requirements of different customers.
Plate UHT sterilizer
Product description: Production capacity: 1-20 t/h.
With such features an high heat recovery, compact and beautiful structrue, stable temperature control etc.
Control methods: Semi-automatic control, full-automatic control (PLC control, touch screen disnplay)
The system adopts ultra-high temperature processing method, which can strictly sterilize the dairy, tea beverage and fruit etc. And then transfe to aseptic packaging. The sterilizing temperature is 135~140 degree and the heat preservation period is 4~5 seconds, so an to maintain the original nutrition, color and flavor of beverage and dairy.
Technology introduction
Technology: 30--70degree--140 degree(4s\10s\15s)--85- 92degree ---(40 degree )return flow
Cooling water 12≤ 30 degree (spare).
Juice sterilizing machine
Tubular UHT sterilizer
Product introduction: The sterilization process of tubular ultra-high temperature sterilizer not only can be suitable for common products, but also can satisfy special requirements of customers, for example: Long term production of products with granules or medium and high viscosity. Such an cream, pure milk etc. Products(milk, fruit juice and cream )of high viscosity: Products containing fiber and larger pulp granules, products of high acidity and products corrosive to the dead angle. The products can be sterilized at high temperature and ultra-high temperature of 120~140 degree
Main features: Hard to agglomerate, long working time; PLC control with simple and correct operation; Touch screen display, which is direct and full; Self-provided CIPcleaning system, easy cleaning; Reliable materials with high pressure withstanding capacity; Low maintenance cost. It can be customized to satisfy infividualized requirements of different customers.
